ANIMATION DE LA TECHNOLOGIE CRYSTALINE DU XYPEX SUR LE BETON

IMPERMEABILITE DU BETON
THE INTERNATIONAL WORLD OF XYPEX


Concrete is the universal product that among many other things, holds water in, and keeps water out. But when concrete fails and water gets through? Big potential problems. This is the story of Xypex around the world, the concrete fixing power of a great product—and how being there with the right stuff has made Xypex a concrete waterproofing leader.


TECHNOLOGIE CRYSTALLINE DE XYPEX
The Xypex crystalline system for concrete waterproofing is substantially different from traditional barrier products — like membranes and cementitious coatings. Check these differences:

- Xypex creates a crystalline structure deep within the pores and capillary tracts of the      concrete mass to prevent the penetration of water and aggressive chemicals. In contrast, barrier-type products function only at the surface of the concrete.

- Because Xypex is not dependent on surface adhesion to achieve its waterproofing effect, it is  resistant to extreme hydrostatic pressure.

- It will seal hairline cracks up to 0.4 mm.

- It is not subject to the deterioration problems encountered by membranes

- Xypex is permanent and reactivates whenever water is present


POROSITE MICROSCOPIQUE NATURELLE DU BETON
CRISTAUX IMPERMEABLES MICROSCOPIQUES REALISES DANS LES PORES NATURELS DU BETON PAR LE XYPEX



XYPEX CONCENTRATE: APPLICATION DU XYPEX SUR UN BETON EXISTANT




XYPEX ADMIX: APPLICATION DU XYPEX DANS UN BETON NEUF


PRODUITS XYPEX - XYPEX PRODUCTS
PLEASE CLICK ON THE PICTURES TO LEARN MORE
VEUILLEZ CLIQUER SUR LES PHOTOS POUR DE PLUS AMPLES INFORMATIONS



XYPEX CONCENTRATE

XYPEX ADMIX
Document
SPECIFICATIONS 'XYPEX CONCENTRATE"
  Document
SPECIFICATIONS "XYPEX ADMIX"


QUELQUES PROJETS DANS LE MONDE REALISE AVEC LE XYPEX


BEIJING OLYMPIC STADIUM 2008

BEIJING OLYMPIC STADIUM 2008
Project Engineer Specifies Xypex to Protect Podium
for Beijing Olympics “Bird’s Nest” Stadium
In major sports venues around the world, Xypex is scoring big. Olympian big! In 2000,
Xypex products played an important part in the waterproofing and protection of the concrete used in the construction of the Olympic Stadium in Sydney. Now, in Beijing, Xypex crystalline technology is again a winning architectural choice where it is being used on the already famous "Bird's Nest" Olympic Stadium. The Bird's Nest, its lacy structure really
does look like a nest, features a high degree of technology and architectural aesthetics. Waterproofing materials used in this landmark project, site of the opening and closing ceremonies at this year's summer Olympics, were required to meet high environmental standards, have good corrosion resistance, durability, permeability and to be non-toxic. Xypex products and crystalline technology met all of the above pre-requisites and was selected by the project engineer to waterproof and protect the concrete diaphragm walls and slabs of the podium. The Beijing Olympic Stadium, with post-event seating of 80,000, is located adjacent to the Beijing National Aquatics Centre. As well as being the venue for the main Olympic ceremonies, it will also be the site for the Games' important track and field events. Once again, Xypex is proud to be playing a functional part in a great international event



WASHINGTON DC METRO SYSTEM
WASHINGTON DC METRO SYSTEM

Xypex products were specified by Bechtel Corp and the Washington Metropolitan Transit Authority for use at various locations of the metro area subway system, including sections in central Washington D.C., Bethesda (Maryland), Chevy Chase (Maryland) and Alexandria (Virginia). Areas of application included tunnel sections, large shotcrete vaults, passageways, mechanical rooms, equipment vaults, elevator shafts and various areas in metro stations. The Xypex system was not only used to treat large surface areas but was also used extensively for the repair of severe leakage problems caused by concrete defects and exposure to strong hydrostatic pressures.


PANAMA CANAL
PANAMA CANAL – GATUN LOCK CULVERTS
Panama

Xypex Admix C-2000 was added to the shotcrete mix and applied to the severely deteriorated walls of these 15 ft. in diameter culverts in the Canal’s Gatun Locks. The original specification had called for the application of Xypex Concentrate followed by shotcrete. However, by using Xypex Admix, the concrete waterproofing and protection process was simplified, project labor time reduced, and substantial cost savings realized


PARIS METRO SYSTEM
PARIS METRO SYSTEM
PARIS, FRANCE

Xypex products were used to seal cracks, joints and water infiltration in various areas of the new and old subway tunnels and stations in this system. The success of these repairs was a major factor in the selection of Xypex by the city of Antwerp for use in their remedial program.


21ST CENTURY TOWER
Dubai, United Arab Emirates


This tower is the tallest residential building in the region. Xypex was used to waterproof and protect the underground water tanks


KUWAIT CITY HOTEL
KUWAIT CITY HOTEL
KUWAIT

Xypex Concentrate was used to waterproof and protect the foundation of this hotel.

WATERFRONT CENTER
WATERFRONT CENTER
VANCOUVER, CANADA

Ten large thermal storage tanks, ten elevator pits and four sump pits were waterproofed with Xypex products at this prominent hotel and office complex located on Vancouver's harbour waterfront. The thermal chambers are below sea level and comprise part of the concrete foundation structure. Total area treated was approximately 7,450 m2 (80,000 sq ft). In addition, Xypex Concentrate and Xypex Patch'n Plug were used to repair approximately 1,200 metres (4,000 lin ft) of construction joints.


POUR D'AUTRES EXAMPLES SUR XYPEX VEUILLEZ CLIQUER SUR CE LINK
PROJETS XYPEX
